Commercial RO Plant

240,000.00 210,000.00

Commercial RO Plant

Particulars

Description

Raw Water Submersible, Storage Tank, Transfer Pump

(BY CLIENT)

Chlorination

In Raw Water Supply For Effective Pre Treatment Of Source Water8 Litres

Filter Cartridges

Sediment, Activated Carbon, UF Membrane

Multi Grade Filter

It’s FRP/S.S. Pressure vessel with internal arrangements and Media of different grades of Sands. The Purpose of Sand Filter is for reduction of Turbidity and Suspended Solids.

Activated Carbon Filter

From MSF Filtered Water is passed through ACF.Which’s a FRP/SS pressure vessel having a bed of carbon in order to remove the Color, Odour & Traces of Organics & free chlorine From MSF Filtered Water is passed through ACF.Which’s a FRP/SS pressure vessel having a bed of carbon in order to remove the Color, Odour & Traces of Organics & free chlorine present in the water.

Antiscalant Dosing System

It’s prevents saturation of various organic salts on R.O. membrane surface. The system comprises of dosing pump and solution.

Micron Cartridge Filter

For removing fine suspended solids . This unit can remove fine solids up to 5 micron, which if carried over can clog the RO membrane

Reverse Osmosis System

R.O. System consists of spirally wound R.O Membranes with FRP/SS Pressure tubes. R.O. is offered for Salt reduction so as to achieve the desired treated water quality.

Chemical Cleaning System

For cleaning of RO Membranes

U.V. System

For Sanitization Of Container As Well As Product.

Commercial RO Plant



QUOTATION FROM AQUAFILTER





From:Aquafilter

Phone: 08604158000, 08604558300

Mail: aquafilter.india@gmail.com

Visit us at www.aquafilter.co.in



GSTIN No. 09BBLPP6257P1ZM



ADDRESS: 8/636 RAJNI KHAND NEAR POWER HOUSE,

LUCKNOW (226012)















 Subject : Your Requirement of 1000 LPH RO Plant















PRICE Rs :     1,80,000 /-   (GST EXTRA)



{ RUPEES – ONE LAKHS EIGHTY THOUSANDS RUPEES ONLY}













Dear Sir,



This has reference to your discussions with undersigned regarding your requirement of 1000

LPH RO Plant..

We trust you will find our offer in line with your requirements. In case should you desire to

have any further confirmation/clarification please feel free to contact us.

Thanking you and assuring you of our best services at all times.

Yours Faithfully,





 AQUAFILTER RO SYSTEMS

Phone: 08604158000, 08604558300

Mail: aquafilter.india@gmail.com

Visit us at www.aquafilter.co.in

















TECHNICAL DETAILS

Designed Raw Water Analysis

Total Dissolved Solids : 1500 ppm [Max]

TREATED WATER PARAMETERS [EX-RO PLANT]

TDS mg/l : < 75 ppm

pH : 5.5 – 6.5





LIMITING CONDITIONS

OF THE PLANT:

  1. OXIDISING ELEMENTS : NIL
  2. IRON : NIL
  3. OIL & GREASE : NIL
  4. WATER SOURCE : BOREWELL
  5. pH : 4 – 11
  6. CHLORINE : NIL
  7. SDI : 3 (Max)





DESIGN PARAMTERS

  1. FEED FLOW : 2000 LPH
  2. PERMEATE FLOW : 1200 LPH
  3. MAXIMUM INLET TDS : 1500 ppm
  4. PERMEATE TDS : < 25 ppm
  5. RECOVERY : 95 %
  6. INLET PRESSURE : 3.0 Kgs/cm2
  7. HP MOTOR RATING : 2.0 HP [2.18 Kw]
  8. POWER : 1-Phase, 220 V AC







SCOPE OF SUPPLY

  1. CARTRIDGE FILTER [5 Micron] : 1 No.
  2. RO MEMBRANES : 40*40 ( CSM/VONTRON)
  3. NO. OF MEMBRANES : 4 ( vontron)
  4. MEMBRANE HOUSING : 2 ( Stainless Steel)
  5. NO. OF HOUSING : 2
  6. HIGH PRESSURE PUMP [SS 304] : One (CRI/LUBI)
  7. PRESSURE GAUGES [0-5 & 0-20] : One Each
  8. SKID [MS] : One
  9. ROF INDICATOR : Two
  10. CONDUCTIVITY INDICATOR [0-200 μs] : One
  11. INTERCONNECTING PIPEWORK : One Lot UPVC
  12. LP SWITCH [PVC] : One
  13. FRP Vessel 13-54 (Pentair make)
  14. Tds ,meter online : 1 (Digital HM)
  15. Frame : 1.5 Inces Stainless Steel

16.Raw Water Pump: 1 HP (USHA/CRI)

























LIST OF SOME PRESTIGIOUS CLIENTS



Below mentioned are the List of Some Prestigious Private as well as Government Clients where we have installed Water cooler along with RO Plant. By this we provide a cold water as well as purified water. We Install these RO plants in Schools, colleges, Hospitals, Government organization & Private organization



EDUCATIONAL INSTITUTIONS.



  • ALLAHABAD PUBLIC SCHOOL,DEWA ROAD,LUCKNOW
  • AMINABAD INTER COLLEGE,LUCKNOW
  • AWADH COLLIGIATE , KANPUR ROAD,LUCKNOW
  • CITY MONTESSORI SCHOOL,LUCKNOW
  • ERAM MEDICAL COLLEGE,UNNAO,LUCKNOW
  • IGNOU LUCKNOW CENTRE
  • PIONEER MONTSKD ACADEMY
  • UNITY COLLEGE,HUSAINABAD,LUCKNOW



GOVERNMENT & NON GOVERNMENT HOSPITALS.

  • Balrampur Hospital ,Lucknow
  • civil Hospital ,Lucknow
  • Ram Manohar Lohia Hospital, Gomtinagar,Lko
  • Awadh Hospital,Lko
  • ShekharHospital,Lko
  • KK hospital,chowk,Lko
  • KamkhyaHospital,chowk,Lko
  • RikhsanaHopspital,Victoriastreet,Lko
  • BrijrajHospital,Thakurganj,Lko
  • ManasHospital,Balaganj,Lko
  • AppoloHospital,Thakurganj,Lko
  • Ama Diagnostic centre,chowk,Lko
  • Galaxy Hospital,Lko
  • CharakHospital,Chowk,Lko
  • PrashasnikBhawan,Alambagh
  • Ambedkar Maidan,Gomtinagar
  • Eco Garden, Alambagh









OTHER TERMS & CONDITIONS

  1. PRICES : These prices Ex-UP Basis
  2. FREIGHT : Shall be borne by you from Lucknow.
  3. DELIVERY : 2 -3 Weeks
  4. TRANSIT INSURANCE : To your account
  5. PAYMENT : 100% advance
  6. 1 year warranty on machine (Membrane is not covered)
